Product Category: pot magnets/holding magnets
Product Features: single side search magnets assembled with disc magnet
Available Grade: N35-N54
Surface Treatment: NiCuNi, Zn, Cr, paint-coated.....
Search magnets are made by assembling disc neodymium magnets into steel cups with special glue,then assembled with eye bolts.The steel cups guide the outer magnetic line of the magnet to the contact surface of the magnets,then extremely strengthen the magnetic force of the contact surface of the search magnets.Meantime,the steel cup also protect the inside neodymium magnet from damaging.Search magnets can be used to salvage ferro-magnetic objects from deep water,cave or anywhere you can not get them by hand.So that search magnets also known as fishing magnets and salvage magnets.
We have single side search magnets and double sides search magnet for sale.Both of the search magnets can be assembled with disc neodymium magnets and ring neodymium magnets.On this page,we just detailed introduce single side search magnet assembled with disc neodymium magnets.It is made by assembled eye bolt on external thread pot magnet.
1. Search magnets have extreme strong holding force,the max breakaway force of the biggest search magnets is up to 600kgs.
2. All magnetic line of the disc magnet are concentrated on the working surface of the search magnet,there are almost no magnetic force on other surfaces of the search magnet.
3. Each search magnet is assembled with a strong eye bolt.
4. The inside disc magnet is made from strongest magnetic material.
1. composition: steel cup with external screw thread,NdFeB disc magnet and steel eye bolt.
2. magnetized direction: magnetized through thickness
3. plating of surface: nickel for magnet part, zinc or nickel for steel parts.
4. color of glue: black,white,red
Item Code | Dimension(mm) | Weight(g) | Magnetic Force(kgs) | ||||
D | D1 | D2 | h | H | |||
SSMD-D25 | 25 | 15 | 21 | 8 | 31 | 35 | 14 |
SSMD-D32 | 32 | 18 | 26 | 8 | 31 | 51 | 25 |
SSMD-D36 | 36 | 18 | 26 | 9 | 38 | 67 | 19 |
SSMD-D42 | 42 | 21 | 34 | 9 | 38 | 97 | 37 |
SSMD-D48 | 48 | 21 | 34 | 11.5 | 45.5 | 172 | 68 |
SSMD-D60 | 60 | 21 | 34 | 15 | 49 | 317 | 112 |
SSMD-D75 | 75 | 26 | 40 | 18 | 60 | 603 | 162 |
SSMD-D80 | 80 | 25 | 40 | 18 | 60 | 800 | 250 |
SSMD-D90 | 90 | 30 | 49 | 18 | 68 | 1000 | 300 |
SSMD-D100 | 100 | 30 | 49 | 18 | 68 | 1200 | 400 |
SSMD-D120 | 120 | 34 | 57 | 18 | 75 | 1800 | 500 |
SSMD-D136 | 136 | 28 | 49 | 28 | 95 | 2500 | 600 |
