External Thread Pot Magnets

External Thread Pot Magnets

Product Category: NdFeB pot magnets/strong holding magnets/ rare-earth magnet pot

Product Features: strong magnetic strength, pot magnets with external thread,pot magnets with screw thread

Available Grade:  N35-N54

Surface Treatment: NiCuNi, Zn, Cr, paint-coated.....

Type-C: external thread magnets, external thread pot magnets, pot magnets with the external thread, external thread neodymium magnets, strong external thread magnets, external screw thread holding magnet.

Thread pot magnets are more and more used today, which including internal thread pot magnets and external thread pot magnets. It is impossible to make a screw thread on a magnet, so thread magnets have to be made with help of other parts - that is the steel cups with the screw thread or steel pot with thread for the screw cap.The whole magnet assembly has more powerful magnetic strength than a naked magnet. The new formed magnetic system just threaded magnets, also called as threaded pot magnets which contain internal threaded pot magnets and external threaded pot magnets.

Under this category, we mainly introduce external threaded magnets or pot magnets with external thread/male thread. This permanent magnet pot assembly is made by sticking a permanent magnet into a steel cup that with the external thread or male thread.Steel nut and screw cap can be fixed on the external thread.We usually glue neodymium disc magnets into the steel cups.The steel cups can not only protect NdFeB magnet discs but also ensure the NdFeB disc magnets stronger magnetic force and holding ability.Our neodymium external thread pot magnets or external thread NdFeB pot magnets are all made from standard grade powerful magnets, the external thread magnets have higher holding force than others.

To meet the needs of different holding force, we provide a wide size range, the diameter of the external pot magnets is from 12mm to 75mm, the thickness is from 5mm to 18mm.The size of the threaded hole is from M3 to M10.

If you just need a little holding force, you may think of ceramic external thread magnets.

Our external thread pot magnets have good market performance.Both of corrosion resistant ability and holding ability are better than those made by competitors.

pot-magnets-cexternal-thread-pot-magnets
pot-magnets-cexternal-thread-pot-magnets

Model

D

M

H

h

Attraction(kg)

Dead Weight(g)

C10

10

3

12

5

2.2

3.5

C12

12

3

13

5

3.2

5

C16

16

4

13

5

5.5

7.5

C20

20

4

15

7

9

16

C25

25

5

17

8

22

30

C32

32

6

18

8

34

45

C36

36

8

18

8

41

57

C42

42

8

20

9

68

84

C48

48

8

24

11.5

81

130

C60

60

10

30

15

113

254
