NdFeB cube magnets are special neo magnet blocks, they have the same size for length,width and height.The NdFeB cube magnets on the picture is measured as 10x10x10mm,it is widely sold by magnet distributors.
For cube shaped neodymium magnets,10x10x10mm is one of the most popular sizes which regularly shipped by us.The magnetic force of a 10mm cube neodymium magnets N52 is about 13.8 LB,even the grade of N35 is strong enough for most of applications.
Characteristics Of Neodymium Cube Magnets 10mm
Remanence(Br): The remanence of 10x10x10mm cube neodymium magnets N35 is 11700-12200Gs, the same size of N52 is 14300-14800 Gs.
Coercivity(HcJ): Hcj of neodymium cube magnets 10mm depends on the working temp., AH-series have the highest Hcj of 33Koe (2642 KA/m).
Magnetic Energy/(B-H)max: The 10mm neodymium cube magnets have the highest (B-H)max range of 35- 52 MGoe .
Operating Temp.: 80℃ for N-series, 100℃ for M-grade, 120℃ for H-grade, 150℃ for SH-grade, 180℃ for UH-grade, 200℃ for EH-grade and 230℃ for AH-grade
Available Coating: Neodymium cube magnets 10x10x10mm are not rust-proof,they are normally plated with Nickel and epoxy.
Specification Of 10mm Neodymium Cube Magnets N45
|
Category
|
Cube magnet
|
|
Material&Grade
|
NdFeB-N45
|
|
Length
|
10 mm
|
|
Width
|
10 mm
|
|
Height
|
10 mm
|
|
Tolerance
|
+/- 0.05 mm
|
|
Direction Of Magnetization
|
Axially(through height)
|
|
Coating
|
Nickel(Ni-Cu-Ni)
|
|
Strength
|
approx. 7 kg
|
|
Max. working temperature
|
80°C
|
|
Color
|
Silver
|
|
Weight
|
7.6 g
|
